Compared to smaller driving simulators, SimDYN steps up to provide a realistic experience for aware to candid drivers. All the attention is on the coherent level of physical and psychological fidelity. To keep realism and immersion at their high levels, one full cockpit is installed on the powerful motion system. AVSimulation uses technologies from the most performant driving simulators in the world, to adapt them into a medium form factor at an attractive price point.
Because the SimDYN driving simulators are used for Human factors, HMI, AD & ADAS or even comfort evaluations, all efforts are put to deliver accurate and coherent cues to the driver.
Items | Descriptions |
---|---|
Driving cockpit | |
Standard vehicle model
| Renault Zoe (4087 x 1787 mm) 5 seats
Modified and instrumented by AVSimulation |
Display system
| |
Resolution
| 12K (11 520 x 2160 pixels)
|
Field of view
| 240°
|
Display frequency
| 60 fps
|
Angular resolution
| Around 1.8 minute of arc
|
Motion system
| |
Degrees of freedom
| 6 DoF (3 translations and 3 rotations)
|
Frequency range
| 0-100 Hz (includes a dedicated vibration system)
|
Software
| |
Included software licenses
| SCANeR
1x Foundation Pack, 4 IG and 1 driver 1x Simulators Pack (6 DoF) |
Options
| Custom vehicle model, motorized access ramp, motorized floor, tracking systems
|
Real scale performances for everyday driving situations.
